PCI Express Gen 3 Test Backplane
The Amfeltec’s PCI Express Gen 3 Test Backplane is an advanced, high-performance testing solution designed to streamline production testing and debugging of PCI Express boards. Ideal for technician in electronics testing and development, this backplane provides reliable simultaneous testing for up to four PCI Express boards at the same time. Built to PCI Express 4.0 standard, it seamlessly connects to a host computer via a CAT7 cable and a choice of PCI Express, MiniPCI Express or ExpressCard® host boards.
Its versatile design, combined with robust overvoltage and overcurrent protection, hot-swap capabilities, and real-time monitoring, makes it dependable platform for efficient testing, programming, and debugging of complex PCI Express boards. Manufactured to stringent RoHS standards, the PCI Express Backplane exemplifies Amfeltec’s commitment to high-quality, innovative solutions for professional-grade testing and development environments.
PCI Express Gen 3 Test Backplane
Benefits and Advantages:
- Accelerated Testing: Dramatically reduce testing time by enabling simultaneous testing of up to four PCI Express boards.
- Convenient Access: Open-concept design facilitates easy replacement of UUTs (Units Under Test) and provides real-time access for signal probing with tools like oscilloscopes or logic analyzers during production testing.
- Enhanced Safety: Independent overcurrent and overvoltage protection for each PCI Express slot safeguards the UUTs, the Test backplane and the Host computer during testing.
- Programmability: Direct access to PCI Express JTAG signals on each slot simplifies testing and programming of UUTs.
- Plug-and-Play Simplicity: Requires no drivers, is OS-agnostic, and allows quick installation and seamless integration into any setup.
- Hot-Swap Functionality: Enables swapping of PCI Express boards without powering down the Host computer, minimizing downtime.
- Versatile Compatibility: Supports a variety of Host boards and PCI Express bifurcation configurations, making it adaptable to diverse testing scenarios.
- PCI Express UUT Stabilization: Features patented support bar (U.S. Patent 7,255,570) for secure, bracket-less mounting of PCI Express UUTs.
PCI Express Gen 3 Test Backplane with UUT
Bracket-less UUT mount stabilization (support bar)
x1 PCI Express Host board
MiniPCI Express Host Board
ExpressCard® Host Board
Designed for Production Testing and Prototype Debugging
The PCI Express Backplane is engineered to support a variety of modern PCI Express board production testing and debugging needs. It extends the Host computer into four x16 PCI Express slots via 10 ft. CAT7 data and 10-pin flat power control cables. Both the backplane and UUTs (Units Under Test, i.e., add-in PCI Express boards) are powered by a standard ATX power supply connected through 24- and 8-pin connectors on the backplane.
Key features include:
- Broad Compatibility: Four PCI Express slots support Gen 1, Gen 2, and Gen 3 speeds (2.5 Gbit/sec, 5 Gbit/sec, and 8 Gbit/sec). Two slots offer a four-lane PCI Express interface, while two provide a 16-lane interface. Both 16-lane slots can handle bifurcation-based configurations, such as x8/x8 or x4/x4/x4/x4 setups.
- Host Connection Options: An x1 PCI Express Gen 2 interface links the backplane to the Host computer. Host boards are available in three variants: PCI Express, MiniPCI Express, and ExpressCard®.
- Efficient Testing: The backplane supports simultaneous testing of up to four PCI Express boards. Real-time power and connection status can be monitored via a USB terminal during testing. Each slot features overvoltage and overcurrent protection, safeguarding both the UUT and testing equipment.
- Hot-Swap Functionality: Replace UUTs without powering down the Host computer, significantly reducing testing downtime.
- Advanced Debugging and Programming: Provides direct access to PCI Express bus JTAG signals for connection to JTAG emulators or the Amfeltec’s eLoader™ in-circuit programmer/loader, facilitating UUT internal component programming before or during testing.
This backplane streamlines production testing, offering reliability, efficiency, and compatibility with a wide range of PCI Express board configurations.
Specifications:
- Four x16 PCI Express Gen 3 slots (4 lanes/16 lanes/16 lanes/4 lanes)
- Two 16 lanes slot support bifurcation x8/x8 and x4/x4/x4/x4
- Overvoltage and overcurrent protection on each slot
- Direct access to PCIe JTAG signals on each slot to support board-level testing and programming (optional)
- Supports Amfeltec’s in-circuit programmer/loader “eLoader™”
- Powered by a standard ATX power supply via 24-pin on backplane connector
- Connect to the Host computer via 10 ft. CAT7 data and 10-pin power control cable
- Host boards: PCI Express, MiniPCI Express, ExpressCard®
- Real-time operation monitoring via USB connection to terminal
- Supports hot-swap operation under Linux and Windows® OS
- Easy “Plug & Play installation, no drivers needed
- Stabilization bar for support bracket-less mount UUT (US Pat. 7,255,570)
- Mounting holes based on ATX Specification 2.0
- Dimension (W x D): 200 mm. x 195 mm.
- Compliant with PCI Express Specification 4.0
- RoHS-compliant
Standard Package Includes:
- PCI Express Gen 3 Test Backplane
- Host Board (choice of PCI Express, MiniPCI Express or ExpressCard®)
- 10 ft. CAT7 data cable
- 10 ft. 10-pin flat Power control cable
- Hot-swap software under Windows® and Linux OS
- Manuals: Product Manual and Software Manual available for download
Part Number:
- SKU-015-01-PCIe PCI Express Gen 3 Test Backplane (x1 PCI Express Host Board)
- SKU-015-01-MPCIe PCI Express Gen 3 Test Backplane (MiniPCI Express Host Board)
- SKU-015-01-ECard PCI Express Gen 3 Test Backplane (ExpressCard® Host Board)
